Precision 64 Cavity PET Preform Mold | High-Efficiency Preform Injection Mould

✅ Precision Engineered: High-grade S136 steel for durability
✅ 64 Cavities: Optimal balance of output and efficiency
✅ Fast Cooling: Reduced cycle times for higher productivity
✅ Customizable: PCO neck finishes & preform weights available
✅ Global Compatibility: Fits Husky, Netstal, Sacmi, and more

Professional-grade injection mold for high-volume bottle preform production. Features precision-machined S136 steel cavities, advanced cooling technology, and compatibility with major injection molding machines. Customizable neck finishes and preform weights available. Factory-direct from Gutewei – quality assured.

Description

Gutewei – Precision Molds for Global Bottle Production

Introducing the Gutewei 64 Cavity PET Preform Mold – the ideal solution for medium-to-high volume bottle manufacturers seeking the perfect balance between production capacity and investment cost. Engineered with advanced cooling technology and precision machining, this mold delivers consistent quality preforms with exceptional cycle time efficiency.

Why Choose Our 64 Cavity Mold?
The 64-cavity configuration is strategically designed for manufacturers who require substantial output without the complexity of ultra-high cavitation molds. It offers optimal compatibility with mid-sized injection molding machines while maintaining the production capacity needed for competitive manufacturing.

Key Features:

Optimized Cavitation: 64 cavities provide excellent production output (8,000 – 12,000 preforms/hour depending on machine and preform weight)
Superior Steel Quality: Constructed from certified S136 stainless steel with vacuum heat treatment for maximum corrosion resistance and longevity
Precision Hot Runner System: Compatible with Husky, Mold-Masters, Yudo, or SINCO hot runner technologies for precise temperature control
Advanced Cooling Technology: Optimized cooling channels with bubbler and baffle systems ensure uniform temperature distribution and reduced cycle times
Interchangeable Components: 100% interchangeable cavities and cores for easy maintenance and reduced downtime

Technical Specifications:

Parameter	Specification
Cavity Count	64 Cavities
Mold Base	LKM / Hasco / DME or Customized
Neck Finishes	PCO 1810, PCO 1881, 38mm, Alaska, Custom
Preform Weight	12g – 55g (Customizable)
Material	PET (Polyethylene Terephthalate)
Steel Grade	S136, 2738, 2311 (Heat Treated)
Injection System	Hot Runner or Cold Runner Options
Guaranteed Life	1.5 – 2 Million Cycles (with proper maintenance)

Applications:

Beverage Industry: Water, carbonated soft drinks, juices, sports drinks
Food Packaging: Edible oils, sauces, condiments
Household Products: Liquid detergents, cleaning solutions
Cosmetic Containers: Custom preforms for personal care products

The Gutewei Advantage:

Factory Direct: No intermediaries – you deal directly with the manufacturer
Custom Engineering: We modify cavity configurations, neck finishes, and preform weights to your exact specifications
Quality Assurance: ISO 9001:2015 quality management system implementation
Global Service: Technical support and spare parts available worldwide
Sample Testing: We provide sample preforms for your quality validation before mass production

Contact Our Sales Team Today
Request a quotation or technical consultation for your 64 cavity PET preform mold project.

The Gutewei 64 Cavity PET Preform Mold offers the perfect balance of productivity and affordability for bottle manufacturers worldwide. Designed with precision engineering and premium materials, this mold ensures consistent preform quality, fast cycle times, and long service life. Whether you're producing water bottles, CSD bottles, or custom containers, our 64-cavity solution delivers reliable performance mold-after-mold. Fully customizable to your preform design and injection machine specifications. Contact Gutewei today for a factory-direct quote!

Gutewei 64 Cavity PET Preform Mold – Technical Specifications

Item	Details
Mold Type	PET Preform Injection Mold
Number of Cavities	64
Mold Dimension	Customizable to your machine
Mold Weight	Approx. 4,500 – 6,500 kg (depending on configuration)
Recommended Machine Tonnage	350 – 550 tons
Steel Material	Cavity/ Core: S136 Heat Treated (48-52 HRC) / Mold Base: 2738 or 2311
Hot Runner System	Optional: Husky, Mold-Masters, Yudo, SINCO, or Hotsys
Cooling System	Advanced baffle & bubbler design with optimal water flow channels
Neck Ring Material	1.2344 ESR Heat Treated
Ejection System	Ejector sleeve or ejector pin design
Surface Treatment	Nitriding / PVD Coating (optional)
Warranty	1 Year or 1 Million Shots
Delivery Time	35 – 50 Days (depending on customization)

We exclusively use premium corrosion-resistant stainless steels such as Assab S136 (Sweden) and Groditz M340 (Germany). Combined with deep vacuum nitriding, surface hardness exceeds HV1000°, with mirror polishing up to Ra≤0.015μm. We guarantee a mold life of over 3 million shots.
Standardized with our in-house developed pneumatic valve gate hot runner system. Multi-zone independent temperature control keeps fluctuation ≤±1℃, preventing material degradation. The gate is automatically sealed after injection, creating a "gate-cut-free" preform that requires no manual trimming — achieving true zero-waste production.
Our 3D conformal cooling channels, designed based on ANSYS simulation, eliminate hot spots and increase cooling efficiency by over 30%. By optimizing the mold structure and injection process, we achieve an injection cycle time of under 10 seconds, significantly boosting your production capacity.
Perfectly compatible with major global injection molding machine brands: HUSKY, NETSTAL, SACMI, KRONES, DEMAG, and all major Chinese manufacturers. Standard interface design for plug-and-play operation.

(Mold Cav Qty)	Neck Size）	Application
18 cav	48mm, 38mm,30/25,20/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
24 cav	48mm,38mm,30/25,29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical, products, edible oil, medicine
32 cav	48mm,38mm,30/25,29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
48 cav	48mm,38mm,30/25,29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
56 cav	48mm, 38mm, 30/25, 29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
72 cav	38mm, 30/25,29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, medicine
96 cav	38mm, 30/25, 29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, medicine
112 cav	30/25, 29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
128 cav	30/25, 29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
144 cav	30/25, 29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine
176 cav	30/25, 29/25, PCO1881, PCO1810	Water, Juice, CSD, Daily chemical products, edible oil, medicine

We are a technology-driven enterprise specializing in the R&D and manufacturing of PET preform molds. Rooted in the industrial heritage of Huangyan, Taizhou – known as "China's Mold Town" – and integrating top-tier German and Japanese machining equipment with Swiss heat treatment processes, we are committed to providing high-cavitation, high-precision, and long-life complete preform molding solutions for the beverage, food, cosmetic, and pharmaceutical packaging industries.
